From the otherpower forums
Famed homebuilt wind turbine inventor Hugh Piggot answers one of my questions
Otherpower forums recently switched over to using the same software as we use on our forum, but for reasons unknown they post messages from old to newer. so to read this you start at the bottom and work your way back up. Brian
I had troubles fitting the images so I pulled the two and deformatted the rest, I hope it is still good
——–
Here is another photo of a 12 metre mast ready to lift using a single lifting cable that passes over the top of the gin pole in this case. As the tower goes up the lifting cable parts company from the descending gin pole and pulls direct. Ultimately it's used as the top guy in this case.
I am struggling a bit to produce pictures with a small enough fiel size that you can actually make out anything useful for some reason.
this is a photo of the previous 20 metre windmill erected. It's taken from the top of another tower. YOu can see the trees behind are pretty large so it has to be at least that high.
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #27 on: August 22, 2010, 12:13:18 PM »
Reply with quote
Hydraulic rams are recently very popular for freestanding towers.
http://www.youtube.com/watch?v=Uro86C2q2no for example. I woudl say that mostly the installers bring the ram and hydraulic pump with them.
I still like the old Tirfor rope-hoist.
Differences between the Otherpower design and mine? They both initially used a too-small disk for the 10 footer. I rated the turbine for low power at first and then later used a larger disk. OP upgraded the magnets. You can go either way, but the larger disk is cheaper and the larger stator is easier to cool.
Otherpower have a nicer looking steel frame but I hope that mine is easier to make.
To be honest I recommend reading both designs and then choosing your own way. That's what a lot of people seem to do. And they mostly add their own ideas, which is when it starts to be fun.
Hugh
Report to moderator Logged
Tanqua
Newbie
*
Posts: 9
View Profile Email Personal Message (Offline)
Re: connecting more than one windmill
« Reply #26 on: August 22, 2010, 10:53:58 AM »
Reply with quote
Ok, that solves the cabling from the turbines.
Just went to check, I have, added together, 6,8m of dia 220, 165 and 110 by 6mm. Think i will add a lenght of dia 100 and 3 guy wires at the top for a tilt-up, have 6 4m pieces of railway line to concrete and make a pivot from. Sound ok to you?
Am toying with the idea of hydraulicly assisting the tower, number of cylinders lying around from old construction and agricultural machines and my tractor has external hyd connections. Friend has Eng firm with contracts at a mine, can get more large dia pipe off-cutts if I need to.
The other two will be guy-wire towers, and the shurflo will have a windmill stand, just love the look of them. Reminds me of growing up on my grandfathers farm.
Hugh, thank you very much for your time and help in sorting out my tower and cabling issue. Now to source the winches and cables.
Have read on the OP site you had hand in designing the Dans turbines. Is there any difference between theirs and yours worth mentioning? To me they look like basically the same thing. Just a matter of curioucity.
Anyone with suggestions regarding a tilt-up with hyd assistance please feel free to raise your voice. Am open for suggestions.
Report to moderator Logged
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #25 on: August 22, 2010, 09:48:39 AM »
Reply with quote
I did help with a system at Temaruru in Zimbabwe that had 4 machines on a hilltop and then they shared a 48 VDC cable to the battery shed. We had some problems with lightning surges blowing the diodes in the rectifier box up there on the hill but the principle was good. I don't recommend paralleling them before you convert to DC. I can't see that working out happily at all.
http://www.scoraigwind.com/powervision/index.htm
Duncan designed them as 'guy wire assisted' free standing towers. They bolted down onto the rock, and the pipes were pretty massive near the bottom but they put guys on them anyway. Belt and braces?
Anyway yes you can do a tilt-up free-standing tower. Why not? Lots of people do that. It costs a lot in steel and in foundations but you get rid of the need for guy wires. Unless you decide to fit them anyway
Hugh
Report to moderator Logged
Tanqua
Newbie
*
Posts: 9
View Profile Email Personal Message (Offline)
Re: connecting more than one windmill
« Reply #24 on: August 22, 2010, 09:29:50 AM »
Reply with quote
I guess since i have not put one up before, and the towers allways looks so thin on photos i'll just have to do it and get it over and done with. I will admit though that i'm not very fond of the idea of all the wasted space around the tower because of the guy-wires as I am planning to put them up as close as safely possible to my house and workshop to keep costs down. I also do know that in order for the turbine to work properly it is of no use putting up a 50cents tower either.
Would it be an option to move them a bit further away then, connect all three together and run a single cable to the batteries?
I am asking this because there would be other structures/sheds/tunnel in the vicinity and I am trying to have the batteries/power room against the house wall and more or less in the centre of things. Hopefully that way I can avoid long cables to a few lights/pumps in the other structures. I should add that I have not started with anything on the property yet, but have bought most of what i need over the last two years. The next step is to gather the goods for the power setup. It is only going to be for 2/3 people to live comfotably and to be selfsustainable.
We do have a supllier in town that sells all sizes/sorts of 3ph cable at better prices that I can source in Cape Town. I have quite a few different sizes and lenghts of cable as well as a number of 6mm/2 rolls of wire by 30m long.
I am aware that there definitely will be power losses in such a system therefore would like to plan well and rather spend money on an extra solar panel than on my own mistakes.
Report to moderator Logged
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #23 on: August 22, 2010, 07:47:51 AM »
Reply with quote
Wall thickness would usually be 5.5 mm on those 3 inch pipes. They do bend and sway a bit, but I am used to that and it doesn't bother me. Most americans choose the next pipe size up but it's not actually necessary for a 1 kW turbine.
Maximum bending load is usually at the top guy level and not at the base as one would assume. The guys prevent it bending at the base – especially if you include plenty of guys on the way up. I usually put in one set of guys per length of pipe i.e. every 6 or 7 metres. The top ones take all of the real load and that's where the pipe will bend in gusty weather, but so long as the furling works right it will not be damaged.
Hugh
Report to moderator Logged
Tanqua
Newbie
*
Posts: 9
View Profile Email Personal Message (Offline)
Re: connecting more than one windmill
« Reply #22 on: August 22, 2010, 05:28:07 AM »
Reply with quote
What is the wall thickness of the pipe/tubing? I would feel "safe" i guess with 4 to 6mm on towers up to 20m or maybe using 4" at the bottom.
Report to moderator Logged
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #21 on: August 22, 2010, 01:08:18 AM »
Reply with quote
Quote from: Boss on August 21, 2010, 10:31:50 AM
I just love seeing your turbines Hugh,
What kind of material is this tower made from?
Damn beautiful country on your island
Thanks for sharing
Brian
I make towers from ordinary steel pipe. Or Circular Hollow Section as they call it. I use 3 inch size (89mm) for the 12 foot turbines (3.6 metre/AWP). I don't paint it because I found that makes the rusting worse, once it gets going. Here things rust fast, but I find that steel pipe forms a surface patina of rust, and then this changes very little over long periods of time. But if it is painted, it forms deep blisters and rusts right through quite fast. So leaving them bare works best for me.
Yes it is pretty amazingly beautiful here I think, which is why I find it hard to go away. I will be travelling a lot in the next couple of months including teaching courses in Wales, Ireland, and three for SEI in the USA, but I always look forward to going home too.
Report to moderator Logged
Tanqua
Newbie
*
Posts: 9
View Profile Email Personal Message (Offline)
Re: connecting more than one windmill
« Reply #20 on: August 21, 2010, 03:47:04 PM »
Reply with quote
Thanks everybody, and for the pics and advice about the tower Hugh. Will def reconcider, maybe just do the tower for the shurflo on a windmill stand to help on cloudy days.
Report to moderator Logged
Boss
Sr. Member
****
Posts: 383
http://outfitnm.com
View Profile WWW Email Personal Message (Online)
Re: connecting more than one windmill
« Reply #19 on: August 21, 2010, 10:31:50 AM »
Reply with quote
I just love seeing your turbines Hugh,
What kind of material is this tower made from?
Damn beautiful country on your island
Thanks for sharing
Brian
Report to moderator 67.131.78.219
Brian Rodgers
My sustainable lifestyle site http://outfitnm.com no ads, not selling anything either
TomW
Administrator
SuperHero Member
*****
Posts: 3245
Zubbly Rides his Turbine [RIP]
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #18 on: August 21, 2010, 07:41:04 AM »
Reply with quote
Report to moderator Logged
The truth is the truth even if no one believes it and a lie is a lie even if everyone believes it!
My Auctions on EbaY:
http://shop.ebay.com/i.html?rt=nc&LH_Auction=1&_ipg=&_ssn=tw_surplus
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #17 on: August 21, 2010, 05:01:42 AM »
Reply with quote
Finally here is a link to a video I did last year showing some simple guyed towers being lowered and erected by a neighbour, Nigel.
http://www.youtube.com/watch?v=T_VrumkFx4E
and there are a few pages about tilt-up tower design and erection in my Recipe Book, now available in Amazon Kindle format.
http://www.amazon.com/Wind-Turbine-Recipe-Book-ebook/dp/B003XVZADA/
Report to moderator Logged
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #16 on: August 21, 2010, 01:30:01 AM »
Reply with quote
Here is another photo of a 12 metre mast ready to lift using a single lifting cable that passes over the top of the gin pole in this case. As the tower goes up the lifting cable parts company from the descending gin pole and pulls direct. Ultimately it's used as the top guy in this case.
* PICT0458.jpg (144.8 KB. 449×337 – viewed 168 times.)
I am struggling a bit to produce pictures with a small enough fiel size that you can actually make out anything useful for some reason.
* PICT0122.jpg (64.5 KB. 193×303 – viewed 168 times.)
this is a photo of the previous 20 metre windmill erected. It's taken from the top of another tower. YOu can see the trees behind are pretty large so it has to be at least that high.
* PICT0458.jpg (144.8 KB, 449×337 – viewed 168 times.)
* PICT0122.jpg (64.5 KB, 193×303 – viewed 168 times.)
Report to moderator Logged
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #15 on: August 21, 2010, 01:09:12 AM »
Reply with quote
* PICT1714.jpg (112.72 KB. 323×430 – viewed 169 times.)
did it work this time… ?
* PICT1714.jpg (112.72 KB, 323×430 – viewed 169 times.)
Report to moderator Logged
scoraigwind
Sr. Member
****
Posts: 284
View Profile WWW Personal Message (Offline)
Re: connecting more than one windmill
« Reply #14 on: August 21, 2010, 01:06:24 AM »
Reply with quote
Quote from: fabricator on August 20, 2010, 04:33:18 PM
Do a search on guyed tilt up towers, no fancy equipment needed and no climbing the tower, ever, a mid size tower can be raised with a hand winch.
Here is a photo of my 20 metre tower with a 3.6 metre diameter turbine on it. I lowered it in June because the tail had jammed. I used a 1.6 tonne rope hoist to lower it, and it was pretty easy to do. It was the first time I took it down since first putting it up in Spring of 2007. The gin pole is about 7 metres long and there are guys from the gin pole to the tower in 3 places. The hoist is attached to the end of the gin pole. I remove the guys from the anchor after attaching the hoist between the anchor and the gin pole. The anchor is about 20 metres from the tower base. The gin pole has its own, shorter guys. When the tower is vertical, the gin pole is sitting a bit above horizontal so that the hoist can apply some tension to the gin pole guys even at the end of the lift.
Filed Under :
Sep.2,2010
Tags :
Martin LaMonica is a senior writer for CNET's Green Tech blog. He started at CNET News in 2002, covering IT and Web development. Before that, he was executive editor at IT publication InfoWorld. E-mail Martin.
The unrest
Potato patch is bristling with food beneath the lovely compost from Slim's sawmill
